FGS 300/DP1


FGS 300/DP1

As suspended ceilings and panel ceilings become a part of modern architecture, the lighting industry has been developing fixtures to suit these ceilings.LITPA's suspended ceiling fixtures are designed to provide creative lighting solutions which are efficient and at the same time easily accessible for service. Fixtures are designed in different sizes and assembly styles for different ceiling types.



Fixture Housings: FGS fixture series are manufactured of 0.6 mm thick high quality steel. The housings are coated with 50 microns electrostatic paint. In order to maximise the efficiency of light and prevent non-symmetry double sockets are used for each bulb. The imported fixture sockets used have phosphorus-bronze fuses with locking mechanisms. In order to minimise energy loss, magnetic or electronic ballasts with low energy loss are used. A special mounting spring is used to enable strong mounting of reflectors onto the fixture and also simplify the changing of the bulb. These springs are designed to allow easy assembly and do not damage the reflector. They also ensure that the reflector fits the housing property.



FGS 300 Series are manufactured for Moduler Ceiling type.



Double Parabolic Bright Louvre (DP1): Manufactured from high purity (99.9%) bright aluminum with double parabolic.



Areas of Use: Private offices, computer facilities, conference rooms, management and prestige offices, classrooms, shopping centers and similar indoor applications.



Light Report

Light Data

Catalogue Pages

Code Lamp Cut-Out (mm) Protection Class Weight (gr)
FGS 300/1*18-DP1 WhiteL 18W280*500 mmIP202.900 gr
FGS 300/1*36-DP1 WhiteL 36W280*1183 mmIP204.900 gr
FGS 300/2*18-DP1 WhiteL 18W280*580 mmIP202.950 gr
FGS 300/2*36-DP1 WhiteL 36W280*1183 mmIP205.500 gr
FGS 300/4*18-DP1 WhiteL 18W580*580 mmIP205.000 gr
FGS 300/4*36-DP1 WhiteL 36W580*1183 mmIP2010.000 gr
